Plastik wonn tab kònen bòdi machin

Model:KGS120Y

Kinggle KGS120Y se yon plastik dirab tab wonn kònen bòdi machin pwepare pou wonn table aplikasyon pou bòdi machin. Fully satisfè tab plastik oswa plastik panno èkstruzyon kònen bòdi kondisyon machin, li ofri desen Customized ak bon jan kalite siperyè, ban nou yon kwen konpetitif.

Volim: 2000LPwa: 42T

Voye ankèt

Deskripsyon Product Specification Application Workshop

Kgs 120y 183 plastik wonn tab kònen bòdi machin se kreye pou panèl plastik Tape pwodwi, tankou Table/ Ware House elatriye Customized Platen Kònen Bòdi Machin ka pafè satisfè sa yo kondisyon espesyal pwodiksyon gwosè pwodwi, ak pwodiksyon segondè-vitès pou konsève pou pri a inite.
Gen ladan yon Moog 100 kontwolè epesè, bra robo, ak anba mouche Sistèm, amelyore pwodiktivite ak bon jan kalite.

Karakteristik ak avantaj

Itilize pou pwodwi fabrikasyon nan divès endistri yo. Si li se gwo kapasite kowozyon ki reziste kontenè ki nan endistri chimik la, anbalaj boutèy ak estanda ijyèn strik nan endistri a manje, oswa bwat anbalaj ak aparisyon ekskiz pou pwodwi chimik chak jou, li ka jisteman kontwole satisfè demand divès mache.
Pwosesis la manje adopte teknoloji dènye kri ak optimisé ki baze sou karakteristik sa yo pwodiksyon segondè-kapasite nan machin nan bòdi 120Y. Reyalize avèk presizyon pousantaj koule a ak distribisyon matyè premyè pou asire epesè miray inifòm pandan bòdi a nan pwodwi volim ultra gwo, efektivman ranfòse fòs la estriktirèl nan pwodwi a, ak elimine domaj bon jan kalite ki te koze pa manje inegal.

Specifications

serial number	Material HDPE…	Mold closing oil cylinder(three cylinders)
serial number	Material HDPE…	Machine model:KGS120Z
Specifications
1	Max container capacity	2000 L
2	Output(dry Cycle)	300 PC/HR
3	Machine Dimension(L×W×H)	8.3 M ×3.4 M × 6.8 M
4	Machine weight	42 T
Clamping Unit
1	Clamping force	1800 KN
2	Mold platen size(W×H)	1600 MM×1900 MM
3	Platen openingstroke	600 MM-1800 MM
4	Platen moving stroke	700 MM
5	Max mold size(W×H)	1650 MM×19000 MM
6	Mold thickness	830MM - 1030 MM
Power
1	Servooil pump motor power	25 KW
2	Servo pump displacement	200 L/MIN
3	Blowpressure	0.8 Mpa
4	Air consumption	2 M²/MIN
5	Cooling water pressure	0.3 Mpa
6	Water consumption	120 L/min
7	Average energy consumption	110 KW -130 KW
Extruder unit
1	Screw diameter	120 MM
2	Screw L/D ratio	30 L/D
3	Melting capacit for HDPE	350 Kg/hr
4	Number of heating zone	6 ZONE
5	Screw heating power	32.5 KW
6	Screw fanpower	0.6 KW
7	Extruder motor power	132 KW
Die head
1	Number of heating sections	5 ZONE
2	Heating power	38.8 KW
3	Maxdie-pin diameter	800(950) MM
4	Accumulator capacity	45(60) L
5	(PE)Accumulator weight	33(45) KG
