10l akimile kònen bòdi machin

Model:KGB70A

KGB70A se yon versatile 10L akimile kònen bòdi machin ki fèt pou max 15-lit boutèy kònen bòdi. Kòm yon manifakti machin dirijan boutèy dlo, nou ofri solisyon Customized satisfè kondisyon kliyan an. Machin lan se pa sèlman pou boutèy dlo, resipyan pestisid, ak pwodiksyon chak jou anbalaj chimik, men tou pou ti pwodwi fòm espesyal. Machin sa a satisfè bezwen divès.

Volim: 20LPwa: 7.8t

Voye ankèt

Deskripsyon Product Specification Application

Kgb70a 10l akimile kònen bòdi machin se yon ouvèti fiks ak fèmen modèl, ki adopte doub rale baton synchronous mekanis blocage, lwil oliv Silenn dirèk presyon bloke mwazi, akimilatè silenn mouri tèt serise. Kontwòl sistèm idralik sèvè, vitès repons vit ak ekonomize enèji.
Plis suite pou moun ki konsepsyon espesyal pwodwi pwodwi pwodiksyon, kapab Kontwole fòm nan ak epesè plis presizyon.

Karakteristik ak avantaj

Modèl sa a se yon ouvèti fiks ak fèmen mwazi, lè l sèvi avèk yon doub mare baton synchronous fim fèmen mekanis, ak lwil la silenn presyon dirèk kadna mwazi an
● Depo Silenn mouri seri tèt
● Maksimòm volim 20L
● Apwopriye pou boutèy dlo, resipyan pestisid, ak anbalaj chimik chak jou, elatriye.
● karakteristik nan diferan se ke li se kontwole pa yon sistèm sèvè idwolik reyalize repons vit aksyon ak efikasite enèji segondè.

Specifications

serial number	Material PE、PP、ABS ...	Mold closing oil cylinder(single cylinder)
serial number	Material PE、PP、ABS ...	Machine model:KGB70A
Specifications
1	Max container capacity	20L
2	Output(dry Cycle)	700 PC/HR
3	Machine Dimension(L×W×H)	4.3 M x1.7 M x3.9 M
4	Machine weight	7.8 T
Clamping Unit
1	Clamping force	130 KN
2	Mold platen size(W×H)	680 MM x 600 MM
3	Platen openingstroke	300 MM - 850 MM
4	Platen moving stroke	370 MM
5	Max mold size(W×H)	460 MM×600 MM
6	Mold thickness	310 MM - 380 MM
Power
1	Servooil pump motor power	11KW
2	Servo pump displacement	80 L/MIN
3	Blowpressure	0.8 Mpa
4	Air consumption	0.7 M²/MIN
5	Cooling water pressure	0.3 Mpa
6	Water consumption	60 L/min
7	Average energy consumption	18 KW-22 KW
Extruder unit
1	Screw diameter	70 MM
2	Screw L/D ratio	24 L/D
3	Melting capacit for HDPE	80 Kg/hr
4	Number of heating zone	3 ZONE
5	Screw heating power	12.6 KW
6	Screw fanpower	0.5 KW
7	Extruder motor power	22 KW
Die head
1	Number of heating sections	5 ZONE
2	Heating power	20 KW
3	Maxdie-pin diameter	180 MM
4	Accumulator capacity	3 L
5	(PE)Accumulator weight	2.25 KG
